Post Dilution Mixer |
 |
A462112000 |
Post Dilution Mixer for external dilutors. |
Search Accessories
|
A46ED |
|
Fridge for chemicals |
 |
A46CLFR000 |
The Fridge for Chemicals is used in combination with the 3S Analyzers colorimeter to keep reagents at a stable temperature. This increases the shelf life of the chemicals and accuracy of results. Based on the type of chemistry used for the analyzer, the fridge will be configured with 1 – 4 reagent tubing holes. The fridge is placed beneath the analyzer, just as the reagent bottles would be arranged. Up to four 2 liter bottles can be placed in the fridge.
Available in 110 VAC or 220 VAC version. |
A46CLFR000 – Fridge for Chemicals
|
CL2 CL3 |
|
External compressed air purifier for CO2 free air for TOC analyzers |
 |
A46CO2P000 |
The external air purifier is an optional accessory for TOC and TC analyzers. It is required in applications where the final user has already an instrumental air supply and wants to use it in combination with a 3S analyzer.
The purifier takes an inlet stream of air and outputs a CO2-free very clean stream of compressed air.
This item replaces the internal CO2 removal section of the TOC analyzer, constituted by the compressors and the sodalime filter and gives excellent performances even with low range analysis.
The generator can be operated with external compressed air in the range of 4 bar to max. 10.5 bar.
| Inlet Temperature |
+5 - +30 °C (41 - 86 °F) |
| CO2 outlet concentration |
< 1 ppm |
| Residual hydrocarbons |
< 0.003 ppm |
| Output Dew Point |
-70 °C |
| Operating pressure |
4 -10.5 bar |
|
External Air Purifier
|
TM |
|
Tank for Dilution water with Level switch 30 L |
 |
A46DT00000 |
|
Search Accessories
|
A46ED |
|
Tank for Dilution water with Level switch 50 L |
 |
A46DT00050 |
|
Search Accessories
|
A46ED |
|
Tank for Dilution water with Level switch 100 L |
|
A46DT00100 |
|
Search Accessories
|
A46ED |
|
SS external reservoir with level switch for dilution water |
 |
A46DWLS000 |
SS external reservoir with level switch for dilution water |
Search Accessories
|
3S-CL C2 CL3 TM 3S-UVCOLOR 3S-UVNO3 3S-UV254 3S-UVFL A46ER |
|
SS reservoir for dilution water with level sensor |
|
A46DWLS0ED |
SS container to accumulate dilution water, with level switch and automatic control for refill. The analyzer will consume only what is needed for the analytical cycle – for mounting frame.
|
Search Accessories
|
A46ER |
|
External Dilutor one Motor with Dual pump head - 4,5x dilution - 110VAC |
 |
A46ED1110X0 |
ED1 is a simple dilution system in a small form factor. It consists of one motor with two pump heads, one for the sample and one for dilution water.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding pump sizes, various ratios are available.
The ED1 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED1
|
A46ED1 |
|
External Dilutor one Motor with Dual pump head - 2x dilution - 110VAC |
|
A46ED112X00 |
ED1 is a simple dilution system in a small form factor. It consists of one motor with two pump heads, one for the sample and one for dilution water.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding pump sizes, various ratios are available.
The ED1 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED1
|
A46ED1 |
|
External Dilutor one Motor with Dual pump head - 3x dilution - 110VAC |
|
A46ED115X00 |
ED1 is a simple dilution system in a small form factor. It consists of one motor with two pump heads, one for the sample and one for dilution water.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding pump sizes, various ratios are available.
The ED1 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED1
|
A46ED1 |
|
External Dilutor one Motor with Dual pump head - 4,5x dilution - 230VAC |
|
A46ED1210X0 |
ED1 is a simple dilution system in a small form factor. It consists of one motor with two pump heads, one for the sample and one for dilution water.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding pump sizes, various ratios are available.
The ED1 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED1
|
A46ED1 |
|
External Dilutor one Motor with Dual pump head - 2x dilution - 230VAC |
|
A46ED122X00 |
ED1 is a simple dilution system in a small form factor. It consists of one motor with two pump heads, one for the sample and one for dilution water.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding pump sizes, various ratios are available.
The ED1 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED1
|
A46ED1 |
|
External Dilutor one Motor with Dual pump head - 3x dilution - 230VAC |
|
A46ED125X00 |
ED1 is a simple dilution system in a small form factor. It consists of one motor with two pump heads, one for the sample and one for dilution water.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding pump sizes, various ratios are available.
The ED1 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED1
|
A46ED1 |
|
External Dilutor two motors with single pump head - 10x dilution - 110VAC |
 |
A46ED2110X0 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 20x dilution - 110VAC |
|
A46ED2120X0 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 40x dilution - 110VAC |
|
A46ED2140X0 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 5x dilution - 110VAC |
|
A46ED215X00 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 10x dilution - 230VAC |
|
A46ED2210X0 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 20x dilution - 230VAC |
|
A46ED2220X0 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 40x dilution - 230VAC |
|
A46ED2240X0 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
External Dilutor two motors with single pump head - 5x dilution - 230VAC |
|
A46ED225X00 |
ED2 is a complete dilution system in a small form factor. It consists of two motors and two pump heads, one for each motor.
The sample is drawn from its reservoir by the sample pump and it is mixed with dilution water coming from the other pump. Water and sample are mixed together in the dilution ratio that can be calculated from the corresponding motor speed and pump size, various ratios are available.
The ED2 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED2
|
A46ED2 |
|
Fast Loop External reservoir - polycarbonate |
 |
A46ER000 |
Fast Loop Reservoir without level sensor. The external reservoir allows to have a fast circulation of the sample coming from the process stream. The polycarbonate cylinder allows a clear view of the sample inside of the reservoir. |
Search Accessories
|
A46ER |
|
Fast Loop external reservoir with level switch - polycarbonate |
|
A46ERLS000 |
Fast Loop Reservoir with sample switch to detect loss of sample. The external reservoir allows to have a fast circulation of the sample coming from the process stream. The sample switch will be connected to the analyzer to detect the presence of the sample. The polycarbonate cylinder allows a clear view of the sample inside of the reservoir. |
Search Accessories
|
3S-CL C2 CL3 3S-TM 3S-UVCOLOR 3S-UVNO3 3S-UV254 3S-UVFL A46ER |
|
SS External reservoir – fast loop with level switch – for mounting frame |
 |
A46ERLS000SED |
Stainless steel external reservoir for sample with level sensor. For external dilutor mounting frame. |
Search Accessories
|
A46ER |
|
SS External reservoir – fast loop with level switch with two valves |
|
A46ERLS000SK |
Stainless steel external reservoir for sample with level sensor. |
Search Accessories
|
A46ER |
|
SS External reservoir with level switch for sample |
|
A46ERLS000SS |
Stainless steel external reservoir for sample with level sensor. |
Search Accessories
|
3S-CL C2 CL3 3S-TM 3S-UVCOLOR 3S-UVNO3 3S-UV254 3S-UVFL A46ER |
|
Epoxy-coated steel stand for TOC analyzer |
 |
A46SDTM000 |
The epoxy coated stand is an optimal mounting solution for the TOC analyzer. The stand offers a support where the analyzer can be placed and includes a tray to tidly store all the required chemicals.
This accessory is ideal for applications where wall space is unavailable or the analyzer has to be moved frequently. |
Search Accessories
|
3S-TM |
|
Filtration unit 100 micron 110 VAC |
 |
A46SF10010 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 100 micron 230 VAC |
|
A46SF10020 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
3S-CL C2 CL3 TM 3S-UVCOLOR 3S-UVNO3 3S-UV254 3S-UVFL A46SF |
|
Filtration unit 10 micron 110 VAC |
|
A46SF10100 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 10 micron 230 VAC |
|
A46SF10200 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 300 micron 110 VAC |
|
A46SF30010 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 300 micron 230 VAC |
|
A46SF30020 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 500 micron 110 VAC |
|
A46SF50010 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 500 micron 230 VAC |
|
A46SF50020 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 50 micron 110 VAC |
|
A46SF50100 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Filtration unit 50 micron 230 VAC |
|
A46SF50200 |
The 3S filtration system is connected to a 3S analyzer and filters out suspended solids to provide a clean sample to the analyzer.
The filtration system has an automated backflush system that uses compressed air to clean the filter element.
As the main volume of the sample stream passes through the polypropylene or stainless steel filter quickly, only the sample quantity necessary for the analysis is filtered. This avoids a build-up on the filter element.
The filter assembly is equipped with a programmable electronic timer that controls the backflush operation. The mesh size is also available in 10, 50, 300 and 500 micron, for both 110V and 230V versions. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Mounting set for filtration unit |
 |
A46SFMKIT0 |
Mounting set for filtration unit. Required for filtration unit A46SF10020 and related. Not suitable for filtration unit 10 micron mesh size. |
A46SF50010 – Filtration Unit
|
A46SF |
|
Sampling Pump |
 |
A46SPP0000 |
The Peristaltic Sampling Pump is a single channel pump used to move the sample to a filtration unit or directly to the Fast Loop Reservoir attached to the analyzer. The entire set comes with the Pump Motor, Reduction Gear Box, and the Pump Head.
The Pump Motor has a fixed pumping rate of 1340 rpm. The Reduction Gear Box allows for the reduction of this pumping rate at different ratios (1:20, 1:40, 1:60). The Pump Head housing is polycarbonate, while there are two options for the Rotor Material (Cold Rolled Steel or Stainless Steel).
A plate for wall mounting is included. |
A46SPP0000 – Sampling Pump
|
3S-CL C2 CL3 3S-TM 3S-UVCOLOR 3S-UVNO3 3S-UV254 3S-UVFL A46SPP |
|
Sampling Pump with Stainless Steel Rotor |
|
A46SPP0000SS |
The Peristaltic Sampling Pump is a single channel pump used to move the sample to a filtration unit or directly to the Fast Loop Reservoir attached to the analyzer. The entire set comes with the Pump Motor, Reduction Gear Box, and the Pump Head.
The Pump Motor has a fixed pumping rate of 1340 rpm. The Reduction Gear Box allows for the reduction of this pumping rate at different ratios (1:20, 1:40, 1:60). The Pump Head housing is polycarbonate, while there are two options for the Rotor Material (Cold Rolled Steel or Stainless Steel).
A plate for wall mounting is included. The stainless steel version is used in applications where the environment is corrosive. |
A46SPP0000 – Sampling Pump
|
A46SPP |
|
Stainless steel continuous flow D.50 sensor holder |
 |
A46U10020 |
The SS steel sensor holder allows 3S probes to work with a fast recirculating sample, guaranteeing a quick response time. |
Search Accessories
|
3S-OIW 3S-UVO 3S-PC1000 |
|
External Dilutor ED4 |
 |
ED4 |
ED4 is a complete dilution system with a dedicated reservoir for dilution water and up to two reservoirs for the samples.
Each sample get drawn from its reservoir by a dedicated peristaltic pump and mixed with the required amount of dilution water. A post dilution mixing container guarantees a reliable dilution and fast response time.
Dilution ratio can be calculated from the corresponding motor speed and pump size, various ratios are available. It supports up to 2 different samples.
The ED4 dilutor is available in both 110 and 230 VAC versions. |
External Dilutor ED4
|
A46ED4 |
|
SS stand for TOC analyzer + cabinet for the chemicals |
 |
TRTOCSUPP2 |
The stainless steel stand is an optimal mounting solution for the TOC analyzer. The stand offers a support where the analyzer can be placed and includes a tray to tidly store all the required chemicals. This accessory is ideal for applications where wall space is unavailable or the analyzer has to be moved frequently. The stainless steel construction guarantees resistance to corrosion even in the most harsh industrial conditions. |
Search Accessories
|
TM |
